Experience next-level gaming with the NVIDIA GeForce RTX 5070 Ti, engineered for high-performance PC builds. Featuring 8960 stream processors, a 2300 MHz base clock, and boost speeds up to 2452 MHz, this GPU handles 4K at 480Hz or 8K at 120Hz with ease. Equipped with 16 GB of ultra-fast GDDR7 memory on a 256-bit interface and PCIe 5.0 support, it delivers stunning visuals and smooth gameplay. Advanced features include DLSS 4, RTX Ray Tracing, Reflex 2, and NVIDIA Studio tools. Cooling is optimized with a high-performance fan system. Requires a 750 W+ PSU with a 16-pin connector.
Gainward GeForce RTX 5070 Ti Phoenix-S GS (DLSS 4, 3x DisplayPort, 1x HDMI 2.1)
Specifications
| type | graphics card |
| EAN | 4710562245530 |
| Manufacturer No. |
NE7507TS19T2-GB2031K |
| slot |
PCIe x16 version 5.0 |
| occupied slots | 3 |
| GPU | |
| Designation |
NVIDIA GeForce RTX 5070 Ti |
| GPU class |
NVIDIA GeForce RTX Gaming |
| Clock frequency | 2300 MHz |
| GPU Boost Clock | 2452 MHz |
| Stream processors | 8960 |
| Support |
DirectX 12 Ultimate, OpenGL 4.6 |
| memory | |
| capacity | 16 GB (GDDR7) |
| Connection | 256 bits |
| effective clock | 28 GHz |
| Connections |
1x HDMI version 2.1b, 3x Displayport version 2.1b |
| Power supply | |
| Average consumption | 300 W |
| Connections |
1x 16-pin (12VHPWR) power connector |
| required power supply | min. 750 W |
| cooling | Cooling with fan |
|
Operating systems |
|
| Supports |
Windows 11, Windows 10 |
| feature |
NVIDIA DLSS 4, Reflex 2, RTX Video, RTX Remix, NVIDIA Broadcast, NVIDIA ShadowPlay, NVIDIA Highlights, NVIDIA G-SYNC, NVIDIA App, Game Ready Driver, NVIDIA Studio Driver, NVIDIA GPU Boost, NVENC Encoder: Gen 9, NVENC Decoder: Gen 6, AV1 Encoder and Decoder, Raytracing Cores: Gen 4, TensorCores (AI): Gen 5 |
| Further information |
Max. resolution: 4K at 480Hz or 8K at 120Hz with DSC |
| Notice |
For the power supply, a power supply with a native 16-pin connector or a power supply with 2x 8-pin PCIe for the included adapter is required |
| Accesories | |
| available | Power adapter |
| Dimensions |
Width: 133.1 mm x Height: 60 mm x Depth/Length: 331.9 mm |
| Weight | 1596 g |
