The R-PF700D-HA0B-EU PC power supply, part of the PF series, delivers a robust 700W total output with a highly efficient 696W on the +12V rail. Designed in a sleek black color, it features an ATX form factor and conforms to the ATX12V 2.4 standard. This unit boasts an efficiency of up to 85% and is 80 PLUS 230V EU certified. It offers a comprehensive range of connections, including a 24-pin ATX, 4+4-pin 12V, multiple SATA, and 6+2-pin graphics connectors. The power supply ensures safety with overvoltage, undervoltage, overload, and short circuit protection. Its cooling system includes a quiet 120mm fan. Dimensions are 150mm width, 86mm height, and 140mm depth, making it a compact choice for various gaming builds.
DeepCool PF700 700W, PC power supply (black, 4x PCIe, 700 watts)
| Type | PC power supply |
| Color | black |
| EAN | 6933412711537 |
| Manufacturer no. | R-PF700D-HA0B-EU |
| series | PF |
| Performance | |
| In total | 700W |
| +12V total | 696 W |
| +3.3V/+5V total | 100W |
| Efficiency | Up to 85% |
| Input voltage range | 200-240 volts |
| Input current | 6 A at 230 volts / 50 Hz |
| default | ATX12V 2.4 |
| Design | ATX |
| Certification | 80 PLUS 230V EU |
| current strengths |
|
| +3.3V | 15 A |
| +5V | 15 A |
| +5 Vsb | 2.5A |
| -12V | 0.3A |
| +12V total | 58 A |
| +12 V1 | 58 A |
| Power factor correction | Active PFC |
| connections | 1x 24-pin ATX12V-2.x, 1x 4+4-pin 12V, 2x 4-pin 5.25", 4x 6+2-pin graphics, 6x 15-pin SATA |
| Cable | |
| lengths | Mainboard main connector 24-pin: 1x 55 cm, mainboard additional connectors 8-pin: 1x 61 cm, drive connectors 5.25 inch: 2x 90 cm, drive connectors SATA: 2x 45 cm, 2x 60 cm, 2x 75 cm, graphics connectors 6-/8 -Pin: 2x 51cm, 2x 66cm |
| cooling | |
| Number of fans | 1x 120mm fan |
| Protective functions | Overvoltage protection (OVP), undervoltage protection (UVP), overload protection (OLP/OPP), short circuit protection (SCP) |
| Dimensions | Width: 150mm x Height: 86mm x Depth/Length: 140mm |
