Build a next-gen AMD powerhouse with this MSI X870E ATX AM5 motherboard, ready for Ryzen 7000, 8000G, and 9000 processors. It supports up to 256GB DDR5 across four DIMM slots with speeds up to 8200MHz (OC) for top-tier performance. Expansion is future-proof with PCIe 5.0 x16 for your GPU plus an additional PCIe x16 slot and x1 slot. Storage is fast and flexible with 3x M.2 (with a passive M.2 cooler) and 4x SATA, plus RAID 0/1/5/10 support. Connectivity is premium: Wi-Fi 7, Bluetooth 5.4, and Realtek 5GbE LAN. Rear I/O includes USB4 with DisplayPort 1.4a, USB-C, multiple USB-A ports, HDMI, and optical S/PDIF. Built-in features like USB BIOS Flashback, diagnostic LEDs, integrated I/O shield, and backplate make building and upgrading easy, while RGB/ARGB headers let you customize your lighting.
MSI MAG X870E GAMING MAX WIFI motherboard
|
Basic motherboard characteristics |
|
| Chipset manufacturer | AMD |
| Manufacturer | MSI |
| Chipset | AMD X870E |
| Form factor | ATX |
|
Motherboard processor |
|
| Processor family | AMD |
| processor socket | Socket AM5 |
| Supported processors | Ryzen 7000, Ryzen 8000G, Ryzen 9000 |
| Motherboard memory | |
| Number of DIMM slots | 4x |
| Maximum main memory | 256 GB |
| Storage type | DDR5 |
| Non-ECC, Un-buffered | Yes |
| supported memory clock | up to 8200 MHz |
|
Motherboard expansion slots |
|
| PCI-Express x16 (total) | 2x |
| PCI-Express 5.0 x16 | 1x |
| PCI-Express 4.0 x16 | 1x |
| PCI-Express x1 | 1x |
| M.2 | 3x |
|
Motherboard External Connectors |
|
| HDMI | 1x |
| USB 4.0 | 1x (with DisplayPort 1.4a) |
| USB 3.2 Type-C | 1x |
| USB 3.1 Type-A | 2x |
| USB 3.0 | 2x |
| USB 2.0 | 4x |
| Ethernet (LAN) | 1 x |
| 3.5mm jack | 3x |
| Toslink/S/PDIF (optical) | Yes |
|
Internal motherboard connectors |
|
| SATA 6 GB/s | 4x |
| USB 3.1 Header | 1x (Type-C) |
| USB 3.0 Header | 2 x |
| USB 2.0 Header | 3 x |
| TPM header | Yes |
| Chassis Intrusion Header | Yes |
| MSI tuning controller header 5-pin | Yes |
| RAID | 0/1/5/10 |
| Power connections | 1x 24-pin ATX, 2x 8-pin EPS12V, 1x 8-pin PCIe |
| Audio channels | 7.1 |
| Audio codec | Realtek ALC897 |
| Motherboard cooling | |
| CPU fan 4-pin | 1x |
| 4-pin case fan | 6x |
| 4-pin pump | 1x |
| Motherboard lighting | |
| RGB header 4-pin | 1x |
| ARGB 3-pin header | 3x |
| Lighting color | RGB |
| Motherboard network | |
| LAN Controller | 1x RJ-45 (5GBase-T, Realtek RTL8126VB) |
| Transfer rate | 10/100/1000/2500/5000 Mb/s |
| Wi-Fi | Wi-Fi 7 (WLAN 802.11a/b/g/n/ac/ax/be, 2x2) |
| Bluetooth | 5.4 |
| Motherboard features | |
| USB BIOS Flashback | Yes |
| M.2 passive cooler | 1x |
| Diagnostic LED | Yes |
| Display | Yes |
| Integrated I/O aperture | Yes |
| Backplate | Yes |
| Audio + solid capacitors | Yes |
